Engine
4-stroke, SOHC, 4-valve V-twin, liquid-cooled
Displacement
783cc
Bore x Stroke
85.0 x 69.0mm
Compression Ratio
10.7:1
Maximum Torque
47.0 lb-ft @ 5,500 rpm
Fuel System
DFI® with two 36mm Mikuni throttle bodies
Ignition
TCBI with Electronic Advance
Starting System
Electric
Transmission
Automatic CVT with centrifugal clutch (H,L,N,R)
Final Drive
Selectable 2WD/4WD with locking front differential, shaft
Engine Braking
Yes
Front Suspension / Wheel Travel
Double wishbone, FOX 2.0 LSC Piggyback Shocks, fully adjustable preload, and adjustable compression damping/10.7 in
Rear Suspension / Wheel Travel
Double wishbone, FOX 2.0 LSC Piggyback Shocks, fully adjustable preload, and adjustable compression damping/10.0 in
Front Tires
Maxxis® 27 x 9-14
Rear Tires
Maxxis® 27 x 11-14
Steering
Electric Power Steering (EPS) / rack-and-pinion
Front Brakes
Dual hydraulic discs with two-piston calipers
Rear Brakes
Sealed, oil-bathed, multi-disc
Ground Clearance
12.2 in (max) / 11.2 in (std)
Fuel Capacity
7.9 gal
Turning Radius
17.7 ft
Cargo Bed Dimensions (LxWxH)
17.9 x 47.6 x 8.7 in
Cargo Bed Capacity
249 lb
Payload Capacity
1,000 lb
Seating Capacity
4
Towing Capacity
1,300 lb
Lighting
(4) LED headlights, (2) LED taillights, LED stoplight
Frame
Steel Tube Double-X Reinforcement
Overall Length
125.4 in
Overall Width
62.6 in
Overall Height
80.5 in
Curb Weight
1,638.3 lb* / 1,640.5 lb* CA Model
Wheelbase
88.2 in
Instruments
Multi-function digital meter with speedometer, fuel gauge, clock, hour meter, odometer, dual trip meter and parking-brake indicator, R/N/P/4WD, water temp and low-oil-pressure indicators
Wheel Type
Alloy
Additional Features
Roof
Color Choices
TRUETIMBER® STRATA
Warranty
Kawasaki Strong 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
