Engine
4-stroke single, SOHC, air-cooled
Displacement
233cc
Bore x Stroke
67.0 x 66.0mm
Compression Ratio
9.4:1
Fuel System
DFI® with 32mm Keihin throttle body
Ignition
TCBI with Electronic Advance
Transmission
6-speed, return shift with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
37mm telescopic fork/8.7 in
Rear Suspension / Wheel Travel
Uni-Trak® linkage system and single shock with adjustable spring preload/8.8 in
Front Tire
2.75 x 21
Rear Tire
4.10 x 18
Front Brakes
Single 240mm petal disc with a dual-piston caliper
Rear Brakes
Single 220mm petal disc with single-piston caliper
Frame Type
High-tensile steel, box-section perimeter
Rake/Trail
27.5°/4.6 in
Overall Length
82.9 in
Overall Width
32.9 in
Overall Height
45.9 in
Ground Clearance
10.4 in
Seat Height
34.8 in
Curb Weight
291.1 lb* / 293.3 lb* CA model
Fuel Capacity
2.0 gal
Wheelbase
54.3 in
Color Choices
Battle Gray
Warranty
12 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
