Engine
2-stroke single with exhaust power valve (KIPS), liquid-cooled
Displacement
84cc
Bore x Stroke
48.5 x 45.8mm
Compression Ratio
10.9:1 (low speed) / 9.0:1 (high speed)
Fuel System
28mm Keihin carburetor
Ignition
CDI with Digital Advance
Transmission
6-speed, return shift, with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
36mm inverted telescopic cartridge fork with 20-way compression damping/10.8 in
Rear Suspension / Wheel Travel
Uni-Trak® single shock system with 24-way compression and 21-way rebound damping, plus adjustable spring preload/10.8 in
Front Tire
70/100-17
Rear Tire
90/100-14
Front Brakes
Single 220mm petal disc with dual-piston caliper
Rear Brakes
Single 184mm petal disc with single-piston caliper
Frame Type
High-tensile steel perimeter design with subframe member
Rake/Trail
29°/3.8 in
Overall Length
72.0 in
Overall Width
30.1 in
Overall Height
43.3 in
Ground Clearance
11.4 in
Seat Height
32.7 in
Curb Weight
164.4 lb*
Fuel Capacity
1.32 gal
Wheelbase
49.8 in
Color Choices
Lime Green
Warranty
Not Available
Kawasaki Protection Plus™ (optional)
Not Available
