Engine
4-stroke, air cooled, single
Displacement
89.9cc
Bore x Stroke
47.0 x 51.8mm
Compression Ratio
10.0:1
Fuel System
Mikuni PTE16
Ignition
Solid state CDI
Transmission
Automatic CVT
Final Drive
2WD, Chain
Front Suspension / Wheel Travel
Single A-arm/2.8 in
Rear Suspension / Wheel Travel
Swingarm/2.9 in
Front Tire
AT 18 x 7-8 tubeless
Rear Tire
AT 18 x 9-8 tubeless
Front Brakes
Dual mechanical drums
Rear Brakes
Hydraulic disc
Ground Clearance
At rear axle - 3.9 in
Starting System
Electric with back-up kick-starter
Fuel Capacity
1.4 gal
Electronic Power Steering (EPS)
No
Turning Radius
8.9 ft
Frame Type
Double cradle, steel
Track Front/Rear
26.8/26.0 in
Overall Length
56.1 in
Overall Width
35.6 in
Overall Height
36.4 in
Seat Height
25.6 in
Curb Weight
269.0 lb*
Wheelbase
38.0 in
Color Choices
Lime Green, Battle Gray
Warranty
12 Month Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, 36, or 48 months
