Engine
Type
Water-cooled, single-cylinder 4-stroke engine, four valves, two overhead camshafts and wet sump lubrication
Bore / stroke
80 mm x 62.1 mm
Capacity
313 cc
Rated output
34 hp at 9,250 rpm
Max. torque
20 lbs-ft at 7,500 rpm
Compression ratio
10.9 : 1
Mixture control
Electronic fuel injection
Emission control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
88 mph
Fuel type
Unleaded regular
Electrical system
Alternator
Three-phase alternator 308 W
Battery
12 V / 8 Ah
Power transmission
Clutch
Multi-disc oil bath (anti-hopping) with self-reinforcement
Gearbox
Constant mesh 6-speed gearbox integrated in crankcase
Drive
X-ring chain with shock absorption in the real wheel hub
Chassis / brakes
Frame
Tubular space frame
Front wheel location / suspension
Inverted fork, 41 mm
Rear wheel location / suspension
Cast aluminum dual swing arm, central spring strut, spring pre-load adjustable
Suspension travel, front / rear
7.1" / 7.1"
Wheelbase
55.9"
Caster
3.9"
Steering head angle
63.3°
Wheels
Cast aluminum wheels
Rim, front
2.50 x 19"
Rim, rear
4.00 x 17"
Tire, front
110/80 R19
Tire, rear
150/70 R17
Brake, front
Single disc, diameter 11.8", 4-piston fixed caliper, radially mounted
Brake, rear
Single disc, diameter 9.5", single-piston floating caliper
ABS
BMW Motorrad ABS
Dimension / weights
Seat height
32.8”
(OE low seat: 32.3”, OE high seat: 33.4”
Inner leg curve
73.6”
(OE low seat: 72.4”, OE high seat: 74.8”)
Usable tank volume
3.0 gal.
Reserve
approx. 0.25 gal.
Length
81.7”
Height (excl. mirrors)
48.8”
Width (excl. mirrors)
34.6”
Unladen weight, road ready, fully fueled
386 lbs. 1)
Permitted total weight
760 lbs.
Payload (with standard equipment)
374 lbs.
