Engine
Rated output
201 hp at 12,750 rpm
Type
Oil/water-cooled, four-cylinder, four-stroke, in-line engine with four valves per cylinder
Bore x stroke
80 mm x 49.7 mm
Capacity
999 cc
Max. torque
83 lb-ft at 11,000 rpm
Compression ratio
13.3 : 1
Mixture control
Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire
Performance / fuel consumption
Maximum speed
170 mph
Fuel type
Premium unleaded (max. 5 % ethanol, E5), 98 ROZ/RON, 93 AKI
Electrical system
Alternator
Permanent magnet alternator with 450 W (nominal power)
Power transmission
Clutch
Multiplate clutch in oil bath, slipper clutch, self-reinforcing
Gearbox
Constant-mesh 6-speed gearbox integrated in the transmission housing
Drive
Chain 525 17/47
Chassis / brakes
Frame
Bridge-type frame, cast aluminum, load-bearing engine
Front wheel location / suspension
Upside-down telescopic fork, diameter 45 mm, electronic self-adjusting rebound/compression damping (Dynamic ESA)
Rear wheel location / suspension
Aluminum twin-sided swingarm, DDC Dynamic Damping Control (central shock absorber), adjustable spring preload, rebound and compression stages electronically adjustable
Suspension travel, front / rear
5.4" / 5.4"
Wheelbase
60.9"
Castor
4.62"
Steering head angle
64.9°
Wheels
Aluminum forged wheel
Rim, front
3.50 x 17"
Rim, rear
6.00 x 17"
Tire, front
120/70 ZR17
Tire, rear
200/55 ZR17
Brake, front
Twin disc brake, diameter 320 mm, 4-piston fixed caliper
Brake, rear
Single disc brake, diameter 220 mm, 1-piston floating caliper
ABS
BMW Motorrad Integral ABS (partial integral, can be switched off)
Dimensions / weights
Seat height at unladen weight
33.4"
Inner leg curve at unladen weight
75.0"
Usable tank volume
approx. 5.3 gal
Reserve
approx. 1 gal
Length
85.4" (over rear wheel)
Height
54.4" (above mirror, unladen weight)
Width
33.5" (without accessories)
Unladen weight, road ready, fully fueled
492 lbs 1)
Permitted total weight
992 lbs
Dry weight
465.1 lbs
