Engine
Type
4-cylinder, 4-stroke in-line engine (BMW ShiftCam)
Bore x stroke
3.15” x 1.96”
Capacity999 ccmNominal capacity
205 hp at 13,000 rpm
Max. torque
83 lb-ft at 11,000 rpm
Compression ratio
13.3 : 1
Mixture control
Electronic injection, variable intake pibe
Emission control
Closed-loop three-way catalytic converter
Mileage/consumption
Maximum speed
188 mph
Fuel type
Premium unleaded
Electrical system
Alternator
450 W
Battery
12 V / 5 Ah, lithium-ion
Power transmission
Clutch
Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement
Gearbox
Claw-shifted 6-speed gearbox with straight cut gears
Drive
Chain 525 17/46
Traction control
DTC, slide control
Suspension/brakes
Frame
Bridge-type aluminum laminate frame with load-bearing engine
Front wheel location / suspension
Upside-down telescopic fork, diameter 45 mm, spring preload, rebound and compression stages adjustable
Rear wheel location / suspension
Aluminum swing arm, full-floater pro, central spring strut, adjustable rebound and compression-stage damping, adjustable preload
Suspension travel, front / rear
4.7” / 4.6”
Wheelbase
57.4”
Castor
3.93”
Steering head angle
66.4°
Wheels
Aluminum cast wheels
Rim, front
3.50 x 17"
Rim, rear
6.00 x 17"
Tire, front
120/70 ZR17
Tire, rear
190/55 ZR17 (with M wheels: 200/55 ZR17)
Brake, front
Twin disc brake, Ø 320 mm 4.5 mm, radial 4-piston fixed caliper (5 mm M wheels)
Breake, rear
Single disc brake, diameter 220 mm, 1-piston floating caliper
ABS
BMW Motorrad Race ABS (partial integral), Brake-Slide-Assist
ABS Pro
BMW Motorrad ABS Pro (settings for RAIN, ROAD, DYNAMIC, RACE mode)
Dimensions / weights
Seat height at vehicle curb weight
32.4”
Inner leg curve at vehicle curb weight
72.6”
Usable tank volume
4.35 gal
Reserve
approx. 1 gal
Length
81.6"
Height
47.4”
Width
33.4”
Dry weight
385.8 lbs (M Package 382.0 lbs without battery)
Vehicle curb weight, road-ready, fully fueled 1)
434.3 lbs (M Package 426.6 lbs)
1)Permitted total weight
897 lbs
Payload (with standard equipment)
463 lbs
