Engine
4-stroke single, SOHC, air-cooled
Displacement
144cc
Bore x Stroke
58.0 x 54.4mm
Compression Ratio
9.5:1
Fuel System
20mm Keihin carburetor
Ignition
Digital DC-CDI
Transmission
5-speed, return shift, with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
33mm telescopic fork/7.1 in
Rear Suspension / Wheel Travel
Uni-Trak® linkage system and single shock with 5-way preload adjustability/7.1 in
Front Tire
70/100-17
Rear Tire
90/100-14
Front Brakes
Single 220mm petal disc with a dual-piston caliper
Rear Brakes
Single 186mm petal disc with single-piston caliper
Frame Type
High-tensile steel, box-section perimeter
Rake/Trail
27°/3.3 in
Overall Length
71.7 in
Overall Width
31.1 in
Overall Height
41.3 in
Ground Clearance
9.3 in
Seat Height
30.7 in
Curb Weight
205.0 lb*
Fuel Capacity
1.5 gal
Wheelbase
49.6 in
Color Choices
Lime Green, Battle Gray
Warranty
6 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
