Engine
4-stroke single, SOHC, air-cooled
Displacement
233cc
Bore x Stroke
67.0 x 66.0mm
Compression Ratio
9.4:1
Fuel System
DFI® with 32mm Keihin throttle body
Ignition
TCBI Electronic Advance
Transmission
6-speed, return shift with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
37mm telescopic fork/9.8 in
Rear Suspension / Wheel Travel
Uni-Trak® linkage system and single shock with adjustable spring preload/9.9 in
Front Tire
80/100-21
Rear Tire
100/100-18
Front Brakes
Single 240mm petal disc with a dual-piston caliper
Rear Brakes
Single 220mm petal disc with single-piston caliper
Frame Type
High-tensile steel, box-section perimeter
Rake/Trail
26.5°/4.4 in
Overall Length
80.5 in
Overall Width
33.1 in
Overall Height
47.2 in
Ground Clearance
11.8 in
Seat Height
36.4 in
Curb Weight
253.6 lb* / 262.3 lb* CA Model
Fuel Capacity
1.7 gal
Wheelbase
53.5 in
Color Choices
Lime Green, Battle Gray
Warranty
6 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
