Engine
4-stroke, V-twin, SOHC, liquid-cooled
Displacement
749cc
Bore x Stroke
85.0 x 66.0mm
Compression Ratio
9.3:1
Maximum Torque
42.7 lb-ft @ 4,750 rpm
Fuel System
DFI® with two 36mm throttle bodies
Ignition
Digital DC-CDI
Transmission
Automatic CVT (H,L,N,R)
Final Drive
Selectable 2WD/4WD with variable control front differential lock, shaft
Front Suspension / Wheel TravelDouble wishbone/6.7 inRear Suspension / Wheel TravelDouble wishbone/7.5 inFront TireAT 25 x 8-12Rear TireAT 25 x 10-12Front BrakesDual hydraulic 176mm discs with 2-piston calipersRear BrakesSealed, oil-bathed, multi-disc with independent park brakeGround Clearance9.4 inStarting SystemElectricFuel Capacity5.0 galElectronic Power Steering (EPS)YesTurning Radius10.5 ftTowing Capacity1,250 lbTotal Rack Capacity242.0 lbRack Capacity, Front/Rear88.0/176.0 lbLighting35W headlights, 5W taillight, 21W stoplight
Frame TypeDouble-cradle, high-tensile tubular steelTrack Front/Rear36.4/35.0 inOverall Length86.4 inOverall Width46.5 inOverall Height48.0 inSeat Height35.8 inCurb Weight699.0 lb*Wheelbase50.6 inInstrumentsSpeedometer, odometer, dual trip meters, fuel gauge, engine temp, clock, hour meter and 2WD/4WD icon, plus indicators for EPS, neutral, belt, and oil pressureColor ChoicesBright White, Super Black, Fragment Camo GrayWarranty12 Month Limited WarrantyKawasaki Protection Plus™ (optional)12, 24, 36, or 48 months
