POWER
Engine 4-stroke, DOHC, 4-valve In-Line Four-Cylinder, liquid-cooled
Displacement 999cc
Maximum Horsepower 116.0 hp¹ @ 8,500 rpm
Maximum Torque 73.8 lb-ft @ 8,000 rpm
Bore x Stroke 73.4 x 59.0mm
Compression Ratio 10.6:1
Fuel System EFI
Ignition TCBI with Digital Advance
Starting System Electric
Transmission Continuously Variable Transmission (CVT) with (H,L,N,R)
Final Drive Selectable 4WD with locking front/rear differential, shaft
Engine Braking Yes
Alternator Output (max) 85 amp
Electronic Rider Aids Power Modes, Economical Riding Indicator
CAPABILITY
Front Suspension / Wheel Travel Long-Travel, Double Wishbone/12.7 in
Rear Suspension / Wheel Travel Long-Travel, Double Wishbone/10.1 in
Front Tires Duro 30 x 10-14
Rear Tires Duro 30 x 10-14
Wheel Type 14" Aluminum
Steering Rack-and-pinion w/ Electric Power Steering (EPS)
Front Brakes Dual hydraulic 249mm discs with two-piston calipers
Rear Brakes Dual hydraulic 249mm discs with single-piston calipers
Ground Clearance 13.8/14.6 in (max preload); 13.8 in CA Model
Fuel Capacity 12.9 gal
Turning Radius 15.0 ft
Cargo Bed Dimensions (LxWxH) 37.6 x 49.0 x 12.8 in
Cargo Bed Load Capacity 1,000/600 lb CA Model
Payload Capacity 1,499/1,100 lb CA Model
Seating Capacity 2, bucket seat
Towing Capacity 2,000 lb
Lighting All-LED lighting
DETAILS
Frame Ladder type, tubular steel
Overall Length 125.4 in
Overall Width 64.0 in
Overall Height 82.3 in
Curb Weight 2,066.1/2,068.3 lb* CA Model
Wheelbase 90.7 in
Instruments Digital speedometer, tachometer, fuel gauge, odometer, dual trip meters, total time, trip time, average speed, gear indicator, Driving Mode, Power Mode, clock, water temperature, battery voltage, oil change reminder, Bluetooth indicator, Economical Riding Indicator, maintenance reminder, high beam, neutral, reverse, and warning lights (battery, EPS, CVT, seatbelt, parking indicator, oil pressure, water temperature)
Additional Features Full Cab with HVAC, Adjustable driver/passenger seats, ERGO-FIT®, Full-color TFT Instrumentation with Smartphone Connectivity via RIDEOLOGY THE APP Powersports, USB ports, KQR™ system compatible
Color Choices Ice Gray, Metallic Graystone
Warranty Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional) 12, 24, 36, or 48 months
