Engine
4-stroke, 1 cylinder, SOHC, 2-valve, air-cooled
Displacement
125cc
Bore x Stroke
56.0 x 50.6mm
Compression Ratio
9.8:1
Fuel System
DFI® with 24mm throttle bodies
Ignition
TCBI with Electronic Advance
Transmission
4-speed, return shift
Final Drive
Sealed chain
Maximum Torque
7.1 lb-ft @ 6,000 rpm
Front Suspension / Wheel Travel
Telescopic fork/3.9 in
Rear Suspension / Wheel Travel
Swingarm, single shock/4.1 in
Front Tire
100/90-12
Rear Tire
120/70-12
Front Brakes
Single 200mm petal-style disc
Rear Brakes
Single 184mm petal-style disc
Frame Type
Backbone
Rake/Trail
26.0°/2.7 in
Overall Length
66.9 in
Overall Width
29.5 in
Overall Height
39.6 in
Ground Clearance
6.1 in
Seat Height
31.7 in
Curb Weight
224.8 lb*
Fuel Capacity
2.0 gal
Wheelbase
46.3 in
Color Choices
Candy Lime Green, Metallic Matte Dark Gray, Cypher Camo Gray (Matte)/Metallic Matte Carbon Gray
Warranty
12 Month Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, 36 or 48 months
