Engine
2-stroke single, liquid-cooled
Displacement
64cc
Bore x Stroke
44.5 x 41.6mm
Compression Ratio
8.4:1
Fuel System
24mm Mikuni carburetor
Ignition
CDI with Digital Advance
Transmission
6-speed, return shift, with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
33mm leading axle telescopic fork with 4-way rebound damping/8.3 in
Rear Suspension / Wheel Travel
Uni-Trak® single shock system with stepless 3-turns rebound damping and fully adjustable spring preload/9.4 in
Front Tire
60/100-14
Rear Tire
80/100-12
Front Brakes
Single 180mm disc with single-piston caliper
Rear Brakes
Single 180mm disc with single-piston caliper
Frame Type
High-tensile steel semi-double cradle
Rake/Trail
27°/2.4 in
Overall Length
62.6 in
Overall Width
29.9 in
Overall Height
37.6 in
Ground Clearance
12.0 in
Seat Height
29.9 in
Curb Weight
132.2 lb*
Fuel Capacity
1.0 gal
Wheelbase
44.1 in
Color Choices
Lime Green
Warranty
Not Available
Kawasaki Protection Plus™ (optional)
Not Available
