TECHNICAL DATA
Engine
Type
Water-cooled 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts, dry sump lubrication
Bore x stroke
3.4” x 3.0”
Capacity
895 cc
Rated output
99 hp at 8,500 rpm
Max. torque
67 lb-ft at 6,500 rpm
Compression ratio
13.1 : 1
Mixture control / engine management
Electronic fuel injection
Emission control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
Over 124 mph
Fuel type
Premium Unleaded
Electrical system
Alternator
Permanent magnetic alternator 416 W (nominal power)
Battery
12 V / 12 Ah
Power transmission
Clutch
Multiple-disc wet clutch (anti hopping), mechanically operated
Gearbox
Constant mesh 6-speed gearbox integrated in crankcase
Drive
Endless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
Frame
Bridge-type frame, steel shell construction
Front wheel location / suspension
Upside-down telescopic fork, Ø 1.7"
Rear wheel location / suspension
Cast aluminum dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Suspension travel front / rear
5.3" / 5.5" (135 mm / 142 mm)
(OE suspension lowering kit: 115 mm / 122 mm)
Brake, front
Dual disc brake, floating brake discs, Ø 320 mm, 4-piston radial brake calipers
Wheelbase
59.7" (1,518 mm)
Caster
4.5" (114.3 mm)
Steering head angle
60.5°
Wheels
Cast aluminum wheels
Rim, front
3.50" x 17”
Rim rear
5.50" x 17”
Tires, front
120/70 ZR 17
Tires, rear
180/55 ZR 17
Brake, rear
Single disc brake, Ø 265 mm, single-piston floating caliper
ABS
BMW Motorrad ABS
Dimensions / weights
Length
84.2" (2,140 mm)
Width (incl. mirrors)
32" (815 mm)
Height (excl. mirrors)
44.4" (1,130 mm)
Seat height, unladen weight
32" (OE suspension lowering kit: 30.3", OE low seat: 31.1", OA high seat: 32.8", OA comfort seat: 33", OE extra high seat: 34")
Inner leg curve, unladen weight
71.6" (OE suspension lowering kit: 69", OE low seat: 70.2", OA high seat: 73.2", OA comfort seat: 73.6", OE extra high seat: 74.4")
Unladen weight, road ready, fully fueled
465 lbs (211 kg) 1)
Permitted total weight
947 lbs (430 kg)
Payload (with standard equipment)
482 lbs (219 kg)
Usable tank volume
3.4 gal (13 L)
Reserve
Approx. 0.9 gal (3.5 L)
