Engine
Type
Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft
Bore x stroke
101 mm x 73 mm
Capacity
1,170 cc
Rated output
109 hp at 7,250 rpm
Max. torque
85.5 lbs. at 6,000 rpm
Compression ratio
12.0 : 1
Mixture control
Electronic port fuel injection
Emission Control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
over 124 mph
Fuel type
Unleaded super (premium)
Electrical system
Alternator
Three-phase alternator with 720 Watt nominal power
Battery
12 V / 12 Ah
Power transmission
Clutch
Single dry plate clutch, hydraulically operated
Gearbox
Constant mesh 6-speed gearbox with helical gear teeth
Drive
Shaft drive
Chassis / brakes
Frame
Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use
Front wheel location / suspension
Telescopic forks with 43 mm fixed-tube diameter
Rear wheel location / suspension
Cast aluminum single-sided swing arm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable
Suspension travel, front / rear
4.7" / 4.7"
Wheelbase
58.8”
Caster
4.1"
Steering head angle
63.4°
Wheels
Spoke wheels
Rim, front
3.50 x 17"
Rim, rear
5.50 x 17"
Tire, front
120/70 ZR 17
Tire, rear
180/55 ZR 17
Brake, front
Twin-disc brakes, diameter 12.6", 4-piston calipers
Brake, rear
Single disc brake, diameter 10.4", double-piston floating caliper
ABS
BMW Motorrad ABS Pro
Dimensions / weights
Seat height
31.7”
Inner leg curve
70.3”
Usable tank volume
4.5 gal.
Reserve
app. 0.9 gal
Length
82.9”
Height (incl. mirrors)
48.8”
Width (incl. hand levers)
34.8”
Unladen weight, road ready, fully fueled
483 lbs. 1)
Permitted total weight
948 lbs.
Payload (with standard equipment)
465 lbs.
