Engine
Type
Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft
Bore x stroke
101 mm x 73 mm
Capacity
1,170 cc
Rated output
109 hp at 7,250 rpm
Max. torque
85 lbs-ft. at 6,000 rpm
Compression ratio
12.0 : 1
Mixture control
Electronic port fuel injection / digital engine management with overrun cutoff, twin-spark ignition
Emission Control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
over 124 mph.
Fuel type
Unleaded super(premium)
Electrical system
Alternator
Three-phase alternator with 720 Watt nominal power
Battery
12 V / 12 Ah
Power transmission
Clutch
Single dry plate clutch, hydraulically operated
Gearbox
Claw-shifted six-speed transmission with helical-cut splines
Drive
Shaft drive
Chassis / brakes
Frame
Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removable pillion frame for single ride use
Front wheel location / suspension
Telescopic forks with 43 mm fixed-tube diameter
Rear wheel location / suspension
Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload steplessly adjustable by hook wrench, rebound-stage damping adjustable
Suspension travel, front / rear
4.9" / 5.5"
Wheelbase
60.1”
Caster
4.33”
Steering head angle
61.5°
Wheels
Cast wheels
Rim, front
3.00 x 19"
Rim, rear
4.50 x 17"
Tire, front
120/70 R 19
Tire, rear
170/60 R 17
Brake, front
Twin-disc brakes, diameter 12.6", 4-piston callipers
Brake, rear
Single disc brake, diameter 10.4", double-piston floating calliper
ABS
BMW Motorrad ABS Pro
Dimensions / weights
Seat height
33.5”
Inner leg curve
74.4”
Usable tank volume
4.5 gal.
Reserve
0.9 gal.
Length
85.6”
Height (incl. mirrors)
52.5”
Width (incl. hand levers)
34.1”
Unladen weight, road ready, fully fueled
491.6 lbs. 1)
Permitted total weight
947.9 lbs
Payload (with standard equipment)
456.3 lbs.
