Engine
4-stroke single, SOHC, air-cooled
Displacement
233cc
Bore x Stroke
67.0 x 66.0mm
Compression Ratio
9.4:1
Fuel System
DFI® with 32mm Keihin throttle body
Ignition
TCBI with Electronic Advance
Transmission
6-speed, return shift with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
37mm telescopic fork/8.0 in
Rear Suspension / Wheel Travel
Uni-Trak® linkage system and single shock with adjustable spring preload/8.6 in
Front Tire
110/70-17
Rear Tire
120/70-17
Front Brakes
Single 300mm petal disc with a dual-piston caliper (and ABS)
Rear Brakes
Single 220mm petal disc with single-piston caliper (and ABS)
Frame Type
High-tensile steel, box-section perimeter
Rake/Trail
27.5°/4.6 in
Overall Length
80.7 in
Overall Width
32.9 in
Overall Height
44.1 in
Ground Clearance
9.1 in
Seat Height
33.3 in
Curb Weight
297.7 lb* (ABS), 299.9 lb* (ABS) CA Model / 295.5 lb* (non-ABS), 297.7 lb* (non-ABS) CA Model
Fuel Capacity
2.0 gal
Wheelbase
54.1 in
Color Choices
Lime Green, Oriental Blue
Warranty
12 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
