Engine
4-stroke single, DOHC, liquid-cooled
Displacement
292cc
Bore x Stroke
78.0 x 61.2mm
Compression Ratio
11.1:1
Fuel System
DFI® with 34mm Keihin throttle body
Ignition
TCBI Electronic Advance
Transmission
6-speed, return shift with wet multi-disc manual clutch
Final Drive
Chain
Engine
4-stroke single, DOHC, liquid-cooled
Displacement
292cc
Bore x Stroke
78.0 x 61.2mm
Compression Ratio
11.1:1
Fuel System
DFI® with 34mm Keihin throttle body
Ignition
TCBI Electronic Advance
Transmission
6-speed, return shift with wet multi-disc manual clutch
Final Drive
Chain
Front Suspension / Wheel Travel
43mm inverted telescopic fork with adjustable compression damping /10.0 in
Rear Suspension / Wheel Travel
Uni-Trak® gas charged shock with piggyback reservoir with adjustable compression, rebound damping and spring preload/9.1 in
Front Tire
3.0 x 21
Rear Tire
4.6 x 18
Front Brakes
Single 250mm petal disc with a dual-piston caliper
Rear Brakes
Single 240mm petal disc with single-piston caliper
Frame Type
Semi-Double Cradle
Rake/Trail
26.7°/4.2 in
Overall Length
86.6 in
Overall Width
32.3 in
Overall Height
47.4 in
Ground Clearance
10.8 in
Seat Height
35.2 in
Curb Weight
282.2 lb* / 286.6 lb* CA Model
Fuel Capacity
2.1 gal
Wheelbase
56.5 in
Color Choices
Lime Green, Battle Gray
Warranty
6 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
