Drivetrain
BrakesHayes PrimeCase Gearing (Upper:Lower)15:26Chain Case / Belt DriveRipperDriver2.52 pitch 8 toothDriveshaftStandardDrivetrain TypeRipperEngine Chain420 Non-OringSprocketsRipperTrack Dimensions (W x L x Lug inches)7 x 93 x 1.25Track Name / FeatureRipper
Dimensions
Estimated Dry Weight - Front (lbs/kg)13.0 / 6Estimated Dry Weight - Rear (lbs/kg)59 / 26.8Overall Length - pivot to bumper (in/cm)46 / 116.8
Rear Suspension
HyfaxN/ARail ColorBlackRear Travel - Fixed Fit Kit (in./cm.)10.0 / 25.4Rear Travel - TSS Fit Kit (in./cm.)N/AShocksTimbersled IFPSuspension Arm ColorBlackSuspension TypeRipper 93 Dual Arm
Chassis
BumperN/ABumper ColorBlackChassisRipperFrame ColorBlackGraphicsBlack / WhiteSide Panel ColorBlackSnow FlapN/A
Front Suspension
Ski Hoop ColorBlackSki TypeRipper BalanceSpindleRipperSpindle ColorBlack
Features
Fuel StorageN/AInstall KitsRipper Fixed StrutStorageN/A
