Engine
4-stroke, DOHC, 8-valve parallel-twin, liquid cooled
Displacement
999cc
Bore x Stroke
92.0 x 75.1mm
Compression Ratio
11.5:1
Maximum Torque
76.7 lb-ft @ 7,000 rpm
Fuel System
DFI® with two 50mm throttle bodies
Ignition
TCBI with Electronic Advance
Starting System
Electric
Transmission
Automatic CVT with centrifugal clutch (H,L,N,R)
Final Drive
Selectable 2WD/4WD with locking front differential, shaft
Engine Braking
Yes
Front Suspension / Wheel Travel
Double wishbone, FOX 2.5 LSC Piggyback Shocks, dual-rate coil-over springs, fully adjustable preload, and 24-way adjustable compression damping/18.6 in
Rear Suspension / Wheel Travel
4-link trailing-arm rear suspension, FOX 2.5 LSC Piggyback Shocks, dual-rate coil-over springs, fully adjustable preload, and 24-way adjustable compression damping/21.1 in
Front Tires
Maxxis® Carnivore 31 x 10.00R15 8PR
Rear Tires
Maxxis® Carnivore 31 x 10.00R15 8PR
Steering
Electric Power Steering (EPS) / rack-and-pinion
Front Brakes
Dual hydraulic discs with two-piston calipers
Rear Brakes
Dual hydraulic discs with single-piston calipers
Ground Clearance
14.4 in (max), 13.6 in (std)
Fuel Capacity
10.6 gal
Turning Radius
23.3 ft
Cargo Bed Dimensions (LxWxH)
14.6 x 33.1 x 9.1 in
Cargo Bed Capacity
351 lb
Payload Capacity
1,001 lb
Seating Capacity
4
Towing Capacity
N/A
Lighting
(2) LED headlights, (2) LED taillights, LED stoplight
Frame
Ladder type, tubular steel
Overall Length
157.3 in
Overall Width
68.1 in
Overall Height
79.3 in
Curb Weight
2,163.1 lb* / 2,165.3 lb* CA Model
Wheelbase
125.8 in
Instruments
Multi-function digital meter with bar-style tachometer (2 display options), digital speedometer, bar-style fuel gauge, gear indicator (L, H, N, R), Power Mode, driving mode (2WD/4WD/4WD+Diff Lock) indicator, Economical Riding Indicator, clock, odometer, dual trip meters, hour meter, water temperature, digital battery gauge, bar-style CTV temperature, seatbelt warning lamp, oil warning lamp, engine check lamp, water temperature warning lamp, neutral indicator lamp, reverse indicator lamp, parking indicator lamp, EPS warning lamp, and CVT belt warning lamp.
Wheel Type
Alloy wheels
Additional Features
Roof, WARN® VRX 45 Winch
Color Choices
Pearl Matte Sage Green/Metallic Carbon Gray
Warranty
6 months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
