Engine
4-stroke, SOHC, 4-valve V-twin, liquid-cooled
Displacement
783cc
Bore x Stroke
85.0 x 69.0mm
Compression Ratio
10.7:1
Maximum Torque
47.0 lb-ft @ 5,500 rpm
Fuel System
DFI® with two 36mm Mikuni throttle bodies
Ignition
TCBI with Electronic Advance
Starting System
Electric
Transmission
Automatic CVT with centrifugal clutch (H,L,N,R)
Final Drive
Selectable 2WD/4WD with locking front differential, shaft
Engine Braking
Yes
Front Suspension / Wheel Travel
Double Wishbone; FOX Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.0 in
Rear Suspension / Wheel Travel
Double Wishbone; FOX Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.3 in
Front Tires
Maxxis® 26 x 9-12
Rear Tires
Maxxis® 26 x 11-12
Steering
Electric Power Steering (EPS) / rack-and-pinion
Front Brakes
Dual hydraulic discs with two-piston calipers
Rear Brakes
Sealed, oil-bathed, multi-disc
Ground Clearance
11.2 in
Fuel Capacity
7.9 gal
Turning Radius
16.7 ft
Cargo Bed Dimensions (LxWxH)
27.6 x 43.3 x 10.4 in
Cargo Bed Capacity
600 lb
Payload Capacity
1,109 lb
Seating Capacity
2
Towing Capacity
1,300 lb
Lighting
(2) halogen headlights, (2) incandescent taillights, incandescent stoplight
Frame
Steel Tube Double-X Reinforcement
Overall Length
118.1 in
Overall Width
60.0 in
Overall Height
75.8 in
Curb Weight
1,570.0 lb* /1,572.2 lb* CA Model
Wheelbase
85.8 in
Instruments
Multi-function digital meter with speedometer, fuel gauge, clock, hour meter, odometer, dual trip meter and parking-brake indicator, R/N/P/4WD, water temp and low-oil-pressure indicators
Wheel Type
Steel
Color Choices
Metallic Moondust White/Super Black
Warranty
Kawasaki Strong 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months
