Engine
4-stroke, 4-cylinder, DOHC, 16-valve, liquid-cooled
Displacement
948cc
Bore x Stroke
73.4 x 56.0mm
Compression Ratio
10.8:1
Fuel System
DFI® with Keihin 36mm throttle bodies
Ignition
TCBI with Electronic Advance
Transmission
6-speed, return shift
Final Drive
Sealed chain
Electronic Rider Aids
Economical Riding Indicator, Kawasaki TRaction Control (KTRC - 3 Modes), Anti-lock Brake System (ABS)
Maximum Torque
72.3 lb-ft @ 6,500 rpm
Front Suspension / Wheel Travel
Inverted telescopic fork with (13-way) adjustable compression and rebound (11-way) damping, spring preload (15-turn)/4.7
Rear Suspension / Wheel Travel
Horizontal back-link swingarm with stepless adjustable rebound damping and spring preload/5.5 in
Front Tire
120/70 ZR17
Rear Tire
180/55 ZR17
Front Brakes
Dual 300mm discs with four-piston calipers, ABS
Rear Brakes
Single 250mm disc with single-piston caliper, ABS
Frame Type
Trellis, high tensile steel
Rake/Trail
25.0°/3.9 in
Overall Length
82.7 in
Overall Width
33.3 in
Overall Height
46.9 in
Ground Clearance
5.1 in
Seat Height
32.3 in
Curb Weight
474.1 lb* 50-State Model
Fuel Capacity
4.5 gal
Wheelbase
57.9 in
Color Choices
Metallic Diablo Black
Warranty
12 Month Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, 36, or 48 months
