Power transmission
Clutch
Wet clutch with an anti-hopping function, hydraulic activation
Gearbox
Constant mesh 6-speed gearbox with helical gear teeth
Drive
Shaft drive
Chassis / brakes
Frame
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front wheel location / suspension
BMW Motorrad Telelever; stanchion diameter 1.5" (37 mm), central spring strut
Rear wheel location / suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Suspension travel, front / rear
7.5" / 7.9" (190 mm / 200 mm)
Wheelbase
59.6" (1,514 mm)
Caster
4.0" (100.6 mm)
Steering head angle
64.3°
Wheels
Cast aluminum wheels
Rim, front
3.00 x 19“
Rim, rear
4.50 x 17“
Tire, front
120/70 R 19
Tire, rear
170/60 R 17
Brake, front
Dual disc brake, floating brake discs, diameter 12.0" (305 mm), 4-piston radial calipers
Brake, rear
Single disc brake, diameter 10.9" (276 mm), double-piston floating caliper
ABS
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized)
Dimensions / weights
Seat height
33.5" / 34.3" (850 mm / 870 mm)
(OE lowered suspension 31.5" / 32.3" - 800 mm / 820 mm)
Inner leg curve
1,870 mm / 1,910 mm
(OE lowered suspension 1.750 mm / 1.790 mm)
Usable tank volume
5.2 gallons
Reserve
Approx. 1.1 gallons
Length (over mud guard)
86.9" (2,207 mm)
Height (over windshield)
56.3" (1,430 mm)
Wide
37.5" (952.5 mm)
Unladen weight, road ready, (fully fuelled 1)
549 lbs (249 kg) 1)
Permitted total weight
1,025 lbs (465 kg)
Payload (with standard equipment)
476 lbs (216 kg)
Engine
Type
Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft and variable engine timing system BMW ShiftCam.
Bore x stroke
102.5 mm x 76 mm
Capacity
1,254 cc
Rated output
136 HP at 7,750 rpm
Max. torque
105 lb-ft at 6,250 rpm
Compression ratio
12.5 : 1
Fuel preparation
Electronic intake manifold injection
Emission control
Regulated three-way catalytic converter
Performance / fuel consumption
Maximum speed
over 124 mph
Fuel type
Premium Unleaded
Electrical system
Alternator
Three-phase generator with 510 Watt nominal power
Battery
12 V / 11.8 Ah
