Engine
Rated output
145 hp at 7,750 rpm
Emission control
Closed-loop 3-way catalytic converter
Type
Air/liquid-cooled four-stroke flat twin engine with double overhead and chain driven camshafts (BMW ShiftCam)
Bore x stroke
106.5 mm x 73 mm
Capacity
1,300 cc
Max. torque
110 lb-ft at 6,500 rpm
Compression ratio
13.3 : 1
Mixture control
Electronic intake pipe injection
Performance / fuel consumption
Maximum speed
over 120 mph
Fuel type
Super unleaded, 95 ROZ/RON; adaptive fuel quality regulation, 91-98 ROZ/RON
Electrical system
Alternator
Three-phase alternator with 650 W (nominal power)
Battery
12 V / 10 Ah Lithium-ion battery
Power transmission
Clutch
Wet clutch, slipper clutch, hydraulically operated
Gearbox
Claw-shifted 6-speed gearbox
Drive
Cardan shaft drive
Traction control
BMW Motorrad DTC
Chassis / brakes
Frame
Two-part frame consisting of main frame, bolted rear frame, and load-bearing engine
Front wheel location / suspension
BMW Motorrad EVO-Telelever, handlebar tilting decoupled via flex element, central shock absorber
Rear wheel location / suspension
BMW Motorrad EVO-Paralever, cast aluminum single-sided swingarm, transversal connected swingarm bearings, central WAD spring strut, spring preload fully adjustable
Suspension travel, front / rear
7.5" / 7.9"
Wheelbase
59.8"
Castor
4.4"
Steering head angle
63.8 °
Wheels
Aluminum cast wheels
Rim, front
3.00 x 19“
Rim, rear
4.50 x 17“
Tire, front
120/70 R19
Tire, rear
170/60 R17
Brake, front
Twin disc brake, semi-floating brake discs, diameter 310 mm, 4-piston radial brake caliper
Brake, rear
Single disc brake, diameter 285 mm, 2-piston floating caliper
ABS
BMW Motorrad Full Integral ABS Pro (lean angle optimized)
Dimensions / weights
Seat height at unladen weight
33.4"
Inner leg curve at unladen weight
74.8"
Usable tank volume
5.0 gal
Reserve
approx. 1 gal
Length
87.1" (over splash guard)
Height
55.4" (above windshield)
Width
39.4" (over hand guard)
Unladen weight, road ready, fully fueled
523 lbs 1)
Permitted total weight
1,025 lbs
Payload (with standard equipment)
502 lbs
