Engine
4-stroke, 3-cylinder, DOHC, liquid-cooled, gas
Displacement
812cc
Bore x Stroke
2.83x2.62 in
Compression Ratio
9.5:1
Maximum Torque
48.0 lb-ft @ 3,500 rpm
Fuel System
DFI® with 34mm throttle body
Transmission
Continuously Variable Transmission (CVT) with (H,L,N,R)
Final Drive
Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock
Engine Braking
Yes
Alternator Output (max)
75 amp
Front Suspension / Wheel Travel
Double wishbone/8.7 in
Rear Suspension / Wheel Travel
Double wishbone/8.5 (L) /8.7 (R) in
Front Tires
26x9.00-12, radial
Rear Tires
26x11.00-12, radial
Park Brake Type
Independent, Mechanical Disc
Steering
Electric Power Steering (EPS), Tilt steering
Front Brakes
Dual Disc, 2 piston caliper
Rear Brakes
Dual Disc, 1 piston caliper
Ground Clearance
10.2 in
Fuel Capacity
7.9 gal
Turning Radius
16.0 ft
Cargo Bed Dimensions (LxWxH)
42.7 x 53.7 x 11.0 in (3-person) / 22.0 x 53.7 x 11.0 in (6-person)
Cargo Bed Capacity
999 lb (3-person) / 350 lb (6-person) / 348 lb CA Model
Payload Capacity
1,616.3 lb / 1,263.5 lb CA Model
Seating Capacity
3-person (1 row), 6 person (2 row)
Towing Capacity
2,000 lb
Lighting
(2) Halogen headlights.
Overall Length
133.3 in
Overall Width
64.0 in
Overall Height
77.6 in
Curb Weight
1,911.7 lb*
Wheelbase
92.3 in
Instruments
Multi-function display includes digital speedometer, fuel gauge, odometer, hour meter, clock, dual trip meters, 2WD/4WD indicator, water temperature warning indicator, oil pressure warning indicator, fuel injection warning indicator, CVT and EPS warning indicators, neutral, reverse and parking indicators, seatbelt reminder lamps
Wheel Type
Steel
Color Choices
Timberline Green, Bright White
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24 or 36 months
