Engine
4-stroke, single-cylinder, OHV, air-cooled
Displacement
401cc
Bore x Stroke
3.23x2.99 in
Compression Ratio
8.6:1
Maximum Torque
21.4 lb-ft @ 2,400 rpm
Fuel System
Fuel injection
Transmission
Continuously Variable Transmission (CVT) with (H,L,N,R)
Final Drive
Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock
Engine Braking
No
Alternator Output (max)
22.9 amp
Front Suspension / Wheel Travel
MacPherson Strut/3.1 in
Rear Suspension / Wheel Travel
Unit Swingarm/3.1 in
Front Tires
26x9.00-12
Rear Tires
26x9.00-12
Park Brake Type
Independent, Mechanical Drum
Steering
Rack-and-pinion
Front Brakes
Drum
Rear Brakes
Drum
Ground Clearance
8.1 in
Fuel Capacity
4.2 gal
Turning Radius
11.8 ft
Cargo Bed Dimensions (LxWxH)
35.6 x 40.9 x 9.6 in
Cargo Bed Capacity
399 lb
Payload Capacity
884 lb
Seating Capacity
2
Towing Capacity
1,100 lb**
Lighting
(4) LED headlights, tail/brake lights
Overall Length
106.7 in
Overall Width
52.6 in
Overall Height
75.0 in
Curb Weight
1,098.1 lb*
Wheelbase
70.1 in
Instruments
Fuel gauge, hour meter, oil temp light, parking brake light
Wheel Type
Steel
Additional Features
Roof, Under Seat Storage, LED Headlights, Painted Body Panels
Color Choices
Metallic Onyx Black
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24 or 36 months
