Engine
Rated output
170 hp at 11,000 rpm
Type
Oil/water-cooled, four-cylinder, four-stroke, in-line engine with four valves per cylinder
Bore x stroke
80 mm x 49.7 mm
Capacity
999 cc
Max. torque
84 lb-ft at 9,250 rpm
Compression ratio
12.5 : 1
Mixture control
Electronic intake pipe injection / digital engine management system: BMS-O with throttle-by-wire
Performance / fuel consumption
Fuel type
Premium unleaded (max. 5 % ethanol, E5), 98 ROZ/RON, 93 AKI
Electrical system
Alternator
Permanent magnet alternator with 493 W (nominal power)
Battery
12 V / 12 Ah
Power transmission
Clutch
Multiplate clutch in oil bath, slipper clutch, self-reinforcing
Gearbox
Constant-mesh 6-speed gearbox integrated in the transmission housing
Drive
Chain 525 17/45
Chassis / brakes
Frame
Bridge-type frame, cast aluminum, load-bearing engine
Front wheel location / suspension
Upside-down telescopic fork, diameter 45 mm, electronic self-adjusting rebound/compression damping (Dynamic ESA)
Rear wheel location / suspension
Aluminum double-sided swing arm, central shock absorber, electronic preload adjuster, electronic self-adjusting rebound/compression damping (Dynamic ESA)
Suspension travel, front / rear
5.9" / 5.9"
Wheelbase
60.6"
Castor
4.64"
Steering head angle
64.8°
Wheels
Aluminum cast wheels
Rim, front
3.50 x 17"
Rim, rear
6.00 x 17"
Tire, front
120/70 ZR17
Tire, rear
190/55 ZR17
Brake, front
Twin disc brake, diameter 320 mm, 4-piston fixed caliper
Brake, rear
Single disc brake, diameter 265 mm, 2-piston floating caliper
ABS
BMW Motorrad Integral ABS (partial integral)
Dimensions / weights
Seat height at unladen weight
33.5" (OE lowering: 31.1")
Inner leg curve at unladen weight
75" (OE lowering: 71.2")
Usable tank volume
5.2 gal
Reserve
approx. 1 gal
Length
84.8" (over rear wheel)
Height
57.5" (without mirror)
Width
33.5" (without accessories)
Unladen weight, road ready, fully fueled
500 lbs 1)
Permitted total weight
992 lbs
Payload (with standard equipment)
491.6 lbs
