Motor
Type
Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft and variable engine timing system BMW ShiftCam.
Bore x stroke
102.5 mm x 76 mm
Capacity
1,254 cc
Rated output
136 HP at 7,750 rpm
Max. torque
105 lb-ft at 6,250 rpm
Compression ratio
12.5 : 1
Mixture Control
Electronic intake pipe injection
Emission control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
over 120 mph
Fuel type
Unleaded super, octane number 95 (RON), adaptive fuel quality regulation (91 to 98 RON)
Electrical system
Alternator
Three-phase alternator with 510 Watt nominal power
Battery
12 V / 11.8 Ah
Power transmission
Clutch
Wet clutch with an anti-hopping function, hydraulic activation
Gearbox
Constant mesh 6-speed gearbox with helical gear teeth
Drive
Shaft drive
Chassis / brakes
Frame
Two-section frame, front- and bolted on rear frame, load-bearing engine
Front wheel location / suspension
BMW Motorrad Telelever; stanchion diameter 1.5" (37 mm), central spring strut
Rear wheel location / suspension
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel
Suspension travel, front / rear
8.3" / 8.7" (210 mm / 220 mm)
Wheelbase
59.2" (1,504 mm)
Caster
3.8" (95.4 mm)
Steering head angle
65.1°
Wheels
Cross spoke wheels
Rim, front
3.00 x 19"
Rim, rear
4.50 x 17"
Tire, front
120/70 R 19
Tire, rear
170/60 R 17
Brake, front
Dual disc brake, floating brake discs, diameter 12.0" (305 mm), 4-piston radial calipers
Brake, rear
Single disc brake, diameter 10.9" (276 mm), double-piston floating caliper
ABS
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized)
Dimensions / weights
Seat height
35.0" / 35.8" (890 mm / 910 mm)
Inner leg curve
76.8" / 78.3" (1,950 mm / 1,990 mm)
Usable tank volume
7.9 gallons
Reserve
Approx. 1 gallon
Length (over mud guard)
89.4" (2,270 mm)
Height (over windshield)
57.5" (1,460 mm)
Wide (over hand guard)
38.6" (980 mm)
Unladen weight, road ready, fully fueled
591 lbs 1)
Permitted total weight
1,069 lbs
Payload (with standard equipment)
478 lbs
