Engine
4-stroke, 2-cylinder, OHV 90° V Liquid-cooled
Displacement
617cc
Bore x Stroke
2.99x2.68 in
Compression Ratio
10:3:1
Maximum Torque
34.7 lb-ft @ 2,500 rpm
Fuel System
DFI® with 34mm Mikuni throttle body
Transmission
Continuously Variable Transmission (CVT) with (H,N,R)
Final Drive
2WD, shaft. Dual mode rear differential with differential lock
Engine Braking
No
Alternator Output (max)
23 amp
Front Suspension / Wheel Travel
MacPherson Strut/3.9 in
Rear Suspension / Wheel Travel
DeDion Axle/2.8 in
Front Tires
23x11.00-10
Rear Tires
23x11.00-10
Park Brake Type
Independent, Mechanical Drum
Steering
Rack-and-pinion
Front Brakes
Drum
Rear Brakes
Drum
Ground Clearance
7.5 in
Fuel Capacity
6.3 gal
Turning Radius
11.0 ft
Cargo Bed Dimensions (LxWxH)
46.3 x 51.6 x 11.4 in
Cargo Bed Capacity
800 lb
Payload Capacity
1,327 lb
Seating Capacity
2
Towing Capacity
1,200 lb
Lighting
(2) Halogen headlights (2) tail/brake lights
Overall Length
116.7 in
Overall Width
62.0 in
Overall Height
75.8 in
Curb Weight
1,338.4 lb*
Wheelbase
73.6 in
Instruments
Parking brake warning light, coolant temperature warning light, 12V DC outlet, fuel gauge, hour meter
Wheel Type
Steel
Color Choices
Dark Royal Red
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24 or 36 months
