Engine
4-stroke, 2-cylinder, DOHC, liquid-cooled, gas
Displacement
999cc
Bore x Stroke
92.0 x 75.1mm
Compression Ratio
10.1:1
Maximum Torque
61.5 lb-ft
Fuel System
DFI® with 38mm throttle body
Transmission
Continuously Variable Transmission (CVT) with (L,H,N,R)
Final Drive
Selectable 2WD/4WD, shaft Dual mode rear differential with differential lock
Engine Braking
Yes
Alternator Output (max)
90 amp
Front Suspension / Wheel Travel
Double wishbone/11.0 in
Rear Suspension / Wheel Travel
Double wishbone/10.1 in
Front Tires
26 x 9.00-12, radial
Rear Tires
26 x 11.00-12, radial
Park Brake Type
Independent, Mechanical Disc
Steering
Rack-and-pinion
Front Brakes
Dual Disc, 2 piston caliper
Rear Brakes
Dual Disc, 1 piston caliper
Ground Clearance
11.9 in (max), 11.8 in (std)
Fuel Capacity
7.9 gal
Turning Radius
16.0 ft
Cargo Bed Dimensions (LxWxH)
54.1 x 53.3 x 11.0 in
Cargo Bed Capacity
999 lb / 600.0 lb CA Model
Payload Capacity
1,616.3 lb / 1,263.5 lb CA Model
Seating Capacity
3
Towing Capacity
2,000 lb
Lighting
(2) Halogen headlights. (2) LED headlights
Overall Length
136.6 in
Overall Width
64.0 in
Overall Height
81.1 in
Curb Weight
1,891.9 lb* / 1,894.1 lb* CA Model
Wheelbase
92.3 in
Instruments
Multi-function display includes digital speedometer, fuel gauge, odometer, hour meter, clock, dual trip meters, 2WD/4WD indicator, water temperature warning indicator, oil pressure warning indicator, fuel injection warning indicator, CVT warning indicator, neutral, reverse and parking indicators, seatbelt reminder lamps
Wheel Type
Steel
Additional Features
Roof, Rear Bumper, Additional Under Seat Storage Bin, Rearview Mirror, Hydraulic Cargo Bed Lift, Self-Leveling Rear Suspension, Anti-cinch Seatbelts
Color Choices
Firecracker Red
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, 36, or 48 months
