Front Suspension / Wheel Travel
Double wishbone/8.6 in
Rear Suspension / Wheel Travel
Double wishbone/9.1 in
Front Tires
25 x 10.00-12, radial
Rear Tires
25 x 10.00-12, radial
Park Brake Type
Independent, Mechanical Disc
Steering
Electric Power Steering (EPS), Tilt steering
Front Brakes
Dual Disc, 2 piston caliper
Rear Brakes
Dual Disc, 1 piston caliper
Ground Clearance
10.6 in
Fuel Capacity
9.5 gal
Turning Radius
14.0 ft
Cargo Bed Dimensions (LxWxH)
33.4 x 44.1 x 9.1 in
Cargo Bed Capacity
699 lb / 600 lb CA Model
Payload Capacity
1,200 lb
Seating Capacity
2
Towing Capacity
1,500 lb
Lighting
(2) Halogen headlights. (2) LED headlightsEngine
4-stroke, single cylinder, SOHC, 4-valve liquid-cooled
Displacement
695cc
Bore x Stroke
102.0 x 85.0mm
Compression Ratio
10.3:1
Maximum Torque
42.7 lb-ft @ 5,000 rpm
Fuel System
DFI® with 44mm throttle body
Transmission
Continuously Variable Transmission (CVT) with centrifugal clutch, (H,L,N,R)
Final Drive
Selectable 2WD/4WD, shaft Dual mode rear differential with differential lock
Engine Braking
Yes
Alternator Output (max)
35.7 amp
Front Suspension / Wheel Travel
Double wishbone/8.6 in
Rear Suspension / Wheel Travel
Double wishbone/9.1 in
Front Tires
25 x 10.00-12, radial
Rear Tires
25 x 10.00-12, radial
Park Brake Type
Independent, Mechanical Disc
Steering
Electric Power Steering (EPS), Tilt steering
Front Brakes
Dual Disc, 2 piston caliper
Rear Brakes
Dual Disc, 1 piston caliper
Ground Clearance
10.6 in
Fuel Capacity
9.5 gal
Turning Radius
14.0 ft
Cargo Bed Dimensions (LxWxH)
33.4 x 44.1 x 9.1 in
Cargo Bed Capacity
699 lb / 600 lb CA Model
Payload Capacity
1,200 lb
Seating Capacity
2
Towing Capacity
1,500 lb
Lighting
(2) Halogen headlights. (2) LED headlights
Overall Length
110.0 in
Overall Width
60.0 in
Overall Height
75.8 in
Curb Weight
1,594.2 lb* / 1,596.4 lb* CA Model
Wheelbase
78.9 in
Instruments
Multi-function display includes digital speedometer, fuel gauge, odometer, hour meter, clock, dual trip meters, 2WD/4WD indicator, water temperature warning indicator, EPS warning indicators, neutral, reverse and parking indicators, differential indicator lamp, seatbelt reminder lamps
Wheel Type
Alloy
Additional Features
Roof, Cast Aluminum Wheels
Color Choices
Deep Blue
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24, 36, or 48 months
