Engine
4-stroke, single-cylinder, OHV, air-cooled
Displacement
401cc
Bore x Stroke
3.23x2.99 in
Compression Ratio
8.6:1
Maximum Torque
21.4 lb-ft @ 2,400 rpm
Fuel System
Fuel injection
Transmission
Continuously Variable Transmission (CVT) with (H,L,N,R)
Final Drive
Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock
Engine Braking
No
Alternator Output (max)
22.9 amp
Front Suspension / Wheel Travel
MacPherson Strut/3.1 in
Rear Suspension / Wheel Travel
Unit Swingarm/3.1 in
Front Tires
26x9.00-12
Rear Tires
26x9.00-12
Park Brake Type
Independent, Mechanical Drum
Steering
Rack-and-pinion
Front Brakes
Drum
Rear Brakes
Drum
Ground Clearance
8.1 in
Fuel Capacity
4.2 gal
Turning Radius
11.8 ft
Cargo Bed Dimensions (LxWxH)
35.6 x 40.9 x 9.6 in
Cargo Bed Capacity
399 lb
Payload Capacity
900 lb
Seating Capacity
2
Towing Capacity
1,100 lb**
Lighting
(2) Halogen headlights, tail/brake lights
Overall Length
106.7 in
Overall Width
52.6 in
Overall Height
73.4 in
Curb Weight
1,082.7 lb*
Wheelbase
70.1 in
Instruments
Fuel gauge, hour meter, oil temp light, parking brake light
Wheel Type
Steel
Color Choices
Firecracker Red, Timberline Green
Warranty
Kawasaki STRONG 3-Year Limited Warranty
Kawasaki Protection Plus™ (optional)
12, 24 or 36 months
