Drivetrain
BrakesTimbersled Pre-bleedCase Gearing (Upper:Lower)18:17Chain Case / Belt Drive52-520 X-RingDriver2.86 pitch 6 toothDriveshaftStandardDrivetrain TypeChain DriveEngine Chain520 X-Ring ChainTrack Dimensions (W x L x Lug inches)11.5 x 129 x 2.5Track Name / FeatureTraverse 2.5"
Dimensions
Estimated Dry Weight - Front (lbs/kg)16.0 / 7.25Estimated Dry Weight - Rear (lbs/kg)112 / 51Overall Length68 in (172.7 cm)
Rear Suspension
HyfaxStandardRail ColorNaturalRear Travel - Fixed Fit Kit (in./cm.)12.0 / 30.5Rear Travel - TSS Fit Kit (in./cm.)20.0 / 50.8ShocksTimbersled IFPSuspension Arm ColorBlackSuspension TypeARO
Chassis
BumperIncludedBumper ColorNatural / BlackChassisARO 3 129Frame ColorNatural / BlackGraphicsBlack / TitaniumSide Panel ColorBlackSnow FlapIncluded
Front Suspension
Ski Hoop ColorBlackSki TypeTraverse®SpindleLightweightSpindle ColorBlack
Features
Fuel StorageAccessory (2.9 gal / 11 L)Install KitsARO/RIOT Fixed or TSSStorageAccessory
