Power transmission
ClutchMultiplate clutch in oil bath, slipper clutchDriveEndless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
FrameBridge-type frame, steel shell constructionSteering head angle62°WheelsCross spoke wheelsRim, front2.15 x 21"Rim, rear4.25 x 17"Tire, front90/90 R21Tire, rear150/70 R17Brake, frontTwin disc brake, floating brake discs, diameter 305 mm, 2-piston floating caliperBrake, rearSingle disc brake, diameter 265 mm, 1-piston floating caliperABSBMW Motorrad ABSCastor4.71"Wheelbase62.6"Suspension travel, front / rear9.05” / 8.46”Front wheel location / suspensionUpside-down Gabel, diameter 43 mm, spring pre-load manually adjustable, rebound and compression adjustableRear wheel location / suspensionCast aluminum dual swing arm, central WAD spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable; SA Enduro Paket Pro: central WAD spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable (High/Low Speed)
Dimensions / weights
Seat height at unladen weight34.2" (OE lowering: 32.0"; OE rally seat high: 35.0"; OE rally seat low: 32.8"; OA single seat: 34.2")Reserveapprox. 1 galUnladen weight, road ready, fully fueled482 lbs1)Permitted total weight981 lbsPayload (with standard equipment)498 lbsWidth37.1" (without accessories)Height54.8” (above windshield)Length89.4" (over mud guard)Usable tank volume3.8 galInner leg curve at unladen weight76.1" (OE lowering: 70.8"; OE rally seat high: 77.3"; OE rally seat low: 74.8"; OA single seat: 76.1")
